Doc: HMSI-168-92 Rev: 3.00Netbiter EasyConnect Gateway User Manual
EtherNet/IP Implementation 35
8. EtherNet/IP Implementation
PleserefertotheNetbiterArgosAdministrationManualonconfiguringEtherNet/IP.
8.1 Client
Connection Type
UCMM(Class1and3connectionnotsupported)
Adapter Timeout
1000ms
Services
Thefollowingservicesareimplemented:
Addressing
Class,Instance,Attribute
8.2 Adapter
8.2.1 Identity Object (0x01)
Class Attributes
Noattributesareimplemented.
Instances
Instance1isimplementedwiththefollowingattributes:
Services
Thefollowingservicesareimplemented:
Code Service Name
0x0E Get_Attribute_Single
0x10 Set_Attribute_Single
ID Access Name Value
1 Get Vendor ID 90
2 Get Device Type 100
3 Get Product Code 85
4 Get Revision 1
5 Get Status 1
6 Get Serial Number ...
7 Get Product Name Netbiter
Code Class Instance Service Name
0x01 No Yes Get_Attributes_All
0x0E No Yes Get_Attribute_Single
