5. GPS
5.1 Connecting GPS Devices
 ForinformationonhowtopoweranexternalGPSdevice,pleaserefertothedocumentation
suppliedwiththedevice.
5.1.1 Netbiter EC220
ToconnectaGPSdevicetoNetbiter
EC220,a9‐pinmaleD‐subconnectoris
needed.
5.1.2 Netbiter EC250
ToconnectaGPSdevicetoNetbiter
EC250,a9‐pinfemaleD‐subconnector
isneeded.
5.1.3 Netbiter EC350
TheNetbiterEC350hasabuilt‐inGPSreceiver.TousetheGPSfunction,connectasuitable
GPSantenna(notincluded)totheunit.
5.2 Activating the GPS Function
GPSfunctionalitymustbeactivatedinNetbiterArgosbeforeitcanbeused.Instructionson
howtoactivatethefunctioncanbefoundintheonlinedocumentationinNetbiterArgos.
Pin Function
2 Tx (Transmit to GPS)
3 Rx (Receive from GPS)
5 Ground
Pin Function
2 Tx (Transmit to GPS)
3 Rx (Receive from GPS)
5 Ground
GND Rx Tx
GND
Tx
Rx
