5353
Stripe Hog Systems
Debris Tank
1. Cuto Ball Valve 3. Optional Filter Panels
2. Access Covers 4. Door Seal Point of Contact
1
22
3
4
Airow at the blasting head moves debris mixed
with water from the blasting heads into a debris
bag or, if this truck is equipped with optional lter
panels, directly to the tank, where solid waste and
particles are trapped. The debris bag is mounted
on retaining hooks near the top of the stainless
steel liner. It is designed to break away and slide
out of the tank with the debris during the dumping
procedure. The optional lter panels are hinged
and swing away from the tank walls. They can be
cleaned using a pressure washer set at 2000 psi
(138 BAR) maximum pressure.
The walls and oor of the debris tank are made
of perforated metal. As the water drains out the
sides and bottom of the debris bag or through the
lter panels, it ows into the debris tank where it
accumulates until it is drained. The debris tank is
equipped with two inside access covers that can
be lifted to clean out the debris. The cleanout
bar consists of multiple nozzles for easy cleanout
of ne particles less than 100 microns that have
leached out of the debris bag.
There is an aluminum cuto ball valve that will
close and prevent vacuum ow if the debris tank
becomes too full. The cuto valve reduces the
possibility for excessive water to ow from the
debris tank to the lter canister and damage the
blower. If the tank overlls causing the cuto ball
valve to shut o the ow of vacuum, the vacuum
safety relief valves or Kunkle valves installed on
the vacuum lter canister and the debris tank
will automatically open to prevent damage to the
vacuum recovery system.
