INTRODUCTION
1.12
Imager Duo Operator’s Manual
Figure 1-11 Image Processor Controller PC and Server PC
Refer to the documents which come with the equipment for technical specifications.
Other Components
The other components that complete the Imaging System network are other manufac-
turers’ products. They will be unpacked and installed by Hologic personnel. Please
refer to the documents that came with them for specifications, operation, safety and
maintenance.
Note:
If maintenance is required, contact Hologic Technical Support.
Figure 1-12 Other System Components
Image Processor Controller
Server
Monitor, Keyboard and
Mouse
Postscript Network Printer
Uninterruptable
Power Supply
(shown with battery
backup)
Network Device
