INTRODUCTION
1.18
Imager Duo Operator’s Manual
Protective Conductor
Terminal
To identify any terminal which
is intended for connection to
an external conductor for pro-
tection against electric shock
in case of a fault, or the termi-
nal of a protective earth
(ground) electrode
IEC 60417 Graphical symbols
for use on equipment, symbol
5019
Power on
Indicates that the control
places the equipment in a fully
powered state.
IEC 60417-1 Graphical sym-
bols for use on equipment,
symbol 5007
Power off
Indicates that using the control
will disconnect power to the
device.
IEC 60417-1 Graphical sym-
bols for use on equipment,
symbol 5008
Fuse
To identify fuse boxes or their
location
IEC 60417 Graphical symbols
for use on equipment, symbol
5016
In vitro diagnostic
medical device
Indicates a medical device
that is intended to used as an
in vitro diagnostic medical
device
ISO 15223-1 Medical
devices—Symbols to be used
with medical device labeling
and information to be sup-
plied, Section 5.5.1
Authorized Repre-
sentative in the Euro-
pean Community
Indicates the Authorized Rep-
resentative in the European
Community
ISO 15223-1 Medical
devices—Symbols to be used
with medical device labeling
and information to be sup-
plied, Section 5.1.2
Manufacturer
Indicates the medical device
manufacturer, as defined in
the EU Directi
ves 90/385/EEC, 93/42/EEC
and 98/79/EC
ISO 15223-1 Medical
devices—Symbols to be used
with medical device labeling
and information to be sup-
plied, Section 5.1.1
Date of manufacture
Indicates the date when the
medical device was manufac-
tured
ISO 15223-1 Medical
devices—Symbols to be used
with medical device labeling
and information to be sup-
plied, Section 5.1.3
