INTRODUCTION
1
Imager Duo Operator’s Manual 1.19
Figure 1-14 Symbols Used on This Instrument
Location of Labels Used on the Instrument
Figure 1-15 Label Locations
Warnings Used in this Manual:
WARNING Service Installation Only
This instrument is to be installed by trained Hologic personnel only.
Catalogue number
Indicates the manufacturer's
catalogue number so that the
medical device can be identi-
fied
ISO 15223-1 Medical
devices—Symbols to be used
with medical device labeling
and information to be supplied,
Section 5.1.6
Serial number
Indicates the manufacturer’s
serial number so that a specific
medical device can be identi-
fied
ISO 15223-1 Medical
devices—Symbols to be used
with medical device labeling
and information to be supplied,
Section 5.1.7
IPC Rear
Grounded Outlet
Server Rear
Grounded Outlet
Imaging Station Rear
Grounded Outlet Serial Number
Model/Rating External Connections
Fusing
