BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Counter Value
CCRP
CCRA
PTON
PTPAU
PTPOL
CCRP Int.
Flag PTMPF
CCRA Int.
Flag PTMAF
PTM O/P Pin
(
PTOC=1)
Time
Counter cleared
by CCRP
Pause
Resume
Counter Stop if
PTON bit low
Counter Reset when
PTON returns high
PTM [1:0] = 10
PWM Duty Cycle
set by CCRA
PWM resumes
operation
Output controlled by
other pin-shared function
Output Inverts
When PTPOL = 1
PWM Period
set by CCRP
PTM O/P Pin
(PTOC=0)
PWM Mode
Note: 1. The counter is cleared by CCRP.
2. A counter clear sets the PWM Period
3. The internal PWM function continues running even when PTIO [1:0]=00 or 01
4. The PTCCLR bit has no inuence on PWM operation
To Next Page
