BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
General Description
The series of devices are Flash Memory A/D type 8-bit high performance RISC architecture
microcontroller with fully integrated touch key functions. With all touch key functions provided
internally and with the convenience of Flash Memory multi-programming features, each device has
all the features to offer designers a reliable and easy means of implementing Touch Keyes within
their products applications.
The touch key functions are fully integrated completely eliminating the need for external
components. In addition to the ash program memory, other memory includes an area of RAM Data
Memory as well as an area of true EEPROM memory for storage of non-volatile data such as serial
numbers, calibration data, etc. Analog features include a multi-channel 12-bit A/D converter with
temperature sensor. Protective features such as an internal Watchdog Timer and Low Voltage Reset
functions coupled with excellent noise immunity and ESD protection ensure that reliable operation
is maintained in hostile electrical environments.
These devices also include fully integrated low and high speed oscillators which are exibly used for
different applications. The ability to operate and switch dynamically between a range of operating
modes using different clock sources gives users the ability to optimise microcontroller operation
and minimise power consumption. Easy communication with the outside world is provided using
the internal UART, I
2
C and SPI interfaces, while the inclusion of exible I/O programming features,
Timer modules and many other features further enhance device functionality and exibility.
The touch key devices will nd excellent use in a huge range of modern Touch Key product applications
such as instrumentation, household appliances, electronically controlled tools to name but a few.
Selection Table
Most features are common to all devices. The main features distinguishing them are Memory
capacity, I/O count, Touch Module and key mumber, stack capacity and package types. The
following table summarises the main features of each device.
Part No.
Program
Memory
Data
Memory
Data
EEPROM
I/O A/D
Temp.
Sensor
Time
Base
BS66F340 4k×16 512×8 128×8 26 12-bit×8 √ 2
BS66F350 8k×16 768×8 128×8 40 12-bit×8 √ 2
BS66F360 16k×16 1024×8 128×8 46 12-bit×8 √ 2
BS66F370 32K×16 1536×8 128×8 60 12-bit×8 √ 2
Part No. Timer Module
Touch
Module
Touch
Key
SIM UART Stacks Package
BS66F340
10-bit CTM×2
10-bit PTM×1
16-bit STM×1
3 12 √ √ 8 28SSOP
BS66F350
10-bit CTM×2
10-bit PTM×1
16-bit STM×1
5 20 √ √ 8 44/48LQFP
BS66F360
10-bit CTM×2
10-bit PTM×1
16-bit STM×1
7 28 √ √ 12 44/48LQFP
BS66F370
10-bit CTM×2
10-bit PTM×1
16-bit STM×1
9 36 √ √ 16 44/48/64LQFP
Note: As devices exist in more than one package format, the table reflects the situation for the
package with the most pins.
