• TB0C Register
Bit 7 6 5 4 3 2 1 0
Name TB0ON — — — — TB02 TB01 TB00
R/W R/W — — — — R/W R/W R/W
POR 0 — — — — 0 0 0
Bit 7 TB0ON: Time Base 0 Enable Control
0: Disable
1: Enable
Bit 6~3 unimplemented, read as "0"
Bit 2~0 TB02~TB00: Time Base 0 time-out period selection
000: 2
8
/f
PSC0
001: 2
9
/f
PSC0
010: 2
10
/f
PSC0
011: 2
11
/f
PSC0
100: 2
12
/f
PSC0
101: 2
13
/f
PSC0
110: 2
14
/f
PSC0
111: 2
15
/f
PSC0
• TB1C Register
Bit 7 6 5 4 3 2 1 0
Name TB1ON — — — — TB12 TB11 TB10
R/W R/W — — — — R/W R/W R/W
POR 0 — — — — 0 0 0
Bit 7 TB1ON: Time Base 1 Enable Control
0: Disable
1: Enable
Bit 6~3 unimplemented, read as "0"
Bit 2~0 TB12~TB10: Time Base 1 time-out period selection
000: 2
8
/f
PSC1
001: 2
9
/f
PSC1
010: 2
10
/f
PSC1
011: 2
11
/f
PSC1
100: 2
12
/f
PSC1
101: 2
13
/f
PSC1
110: 2
14
/f
PSC1
111: 2
15
/f
PSC1
Serial Interface Module Interrupt
The Serial Interface Module Interrupt, also known as the SIM interrupt, is contained within the
Multi-function Interrupt. A SIM Interrupt request will take place when the SIM Interrupt request
ag, SIMF, is set, which occurs when a byte of data has been received or transmitted by the SIM
interface, an I
2
C slave address match or I
2
C bus time-out occurrence. To allow the program to
branch to its respective interrupt vector address, the global interrupt enable bit, EMI, the Serial
Interface Interrupt enable bit, SIME, and Muti-function interrupt enable bit must rst be set. When
the interrupt is enabled, the stack is not full and any of the above described situations occurs, a
subroutine call to the respective Multi-function Interrupt vector, will take place. When the Serial
Interface Interrupt is serviced, the EMI bit will be automatically cleared to disable other interrupts,
however only the Multi-function interrupt request ag will be also automatically cleared. As the
SIMF ag will not be automatically cleared, it has to be cleared by the application program.
