BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Register
Name
Bit
7 6 5 4 3 2 1 0
INTEG — — — — INT1S1 INT1S0 INT0S1 INT0S0
INTC0 — TKMF INT1F INT0F TKME INT1E INT0E EMI
INTC1 ADF MF1F MF0F URF ADE MF1E MF0E URE
INTC2 MF3F TB1F TB0F MF2F MF3E TB1E TB0E MF2E
MFI0 — — CTM0AF CTM0PF — — CTM0AE CTM0PE
MFI1 STMAF STMPF CTM1AF CTM1PF STMAE STMPE CTM1AE CTM1PE
MFI2 — SIMF PTMAF PTMPF — SIME PTMAE PTMPE
MFI3 — — DEF LVF — — DEE LVE
Interrupt Registers List
• INTEG Register
Bit 7 6 5 4 3 2 1 0
Name — — — — INT1S1 INT1S0 INT0S1 INT0S0
R/W — — — — R/W R/W R/W R/W
POR — — — — 0 0 0 0
Bit 7~4 Unimplemented, read as "0"
Bit 3~2 INT1S1~INT1S0: Interrupt edge control for INT1 pin
00: Disable
01: Rising edge
10: Falling edge
11: Rising and falling edges
Bit 1~0 INT0S1~INT0S0: Interrupt edge control for INT0 pin
00: Disable
01: Rising edge
10: Falling edge
11: Rising and falling edges
• INTC0 Register
Bit 7 6 5 4 3 2 1 0
Name — TKMF INT1F INT0F TKME INT1E INT0E EMI
R/W — R/W R/W R/W R/W R/W R/W R/W
POR — 0 0 0 0 0 0 0
Bit 7 Unimplemented, read as "0"
Bit 6 TKMF: Touch key interrupt request ag
0: No request
1: Interrupt request
Bit 5 INT1F: INT1 interrupt request ag
0: No request
1: Interrupt request
Bit 4 INT0F: INT0 interrupt request ag
0: No request
1: Interrupt request
Bit 3 TKME: Touch key interrupt control
0: Disable
1: Enable
Bit 2 INT1E: INT1 interrupt control
0: Disable
1: Enable
Bit 1 INT0E: INT0 interrupt control
0: Disable
1: Enable
