BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Bit 2 TB1E: Time Base 1 interrupt control
0: Disable
1: Enable
Bit 1 TB0E: Time Base 0 interrupt control
0: Disable
1: Enable
Bit 0 MF2E: Multi-function 2 interrupt control
0: Disable
1: Enable
• MFI0 Register
Bit 7 6 5 4 3 2 1 0
Name — — CTM0AF CTM0PF — — CTM0AE CTM0PE
R/W — — R/W R/W — — R/W R/W
POR — — 0 0 — — 0 0
Bit 7~6 Unimplemented, read as "0"
Bit 5 CTM0AF: CTM0 Comparator A match Interrupt request ag
0: No request
1: Interrupt request
Bit 4 CTM0PF: CTM0 Comparator P match Interrupt request ag
0: No request
1: Interrupt request
Bit 3~2 Unimplemented, read as "0"
Bit 1 CTM0AE: CTM0 Comparator A match Interrupt control
0: Disable
1: Enable
Bit 0 CTM0PE: CTM0 Comparator P match Interrupt control
0: Disable
1: Enable
• MFI1 Register
Bit 7 6 5 4 3 2 1 0
Name STMAF STMPF CTM1AF CTM1PF STMAE STMPE CTM1AE CTM1PE
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 0 0 0 0 0 0 0 0
Bit 7 STMAF: STM Comparator A match Interrupt request ag
0: No request
1: Interrupt request
Bit 6 STMPF: STM Comparator P match Interrupt request ag
0: No request
1: Interrupt request
Bit 5 CTM1AF: CTM1 Comparator A match Interrupt request ag
0: No request
1: Interrupt request
Bit 4 CTM1PF: CTM1 Comparator P match Interrupt request ag
0: No request
1: Interrupt request
Bit 3 STMAE: STM Comparator A match Interrupt control
0: Disable
1: Enable
Bit 2 STMPE: STM Comparator P match Interrupt control
0: Disable
1: Enable
