BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Symbol Parameter
Test Conditions
Min. Typ. Max. Unit
V
DD
Conditions
I
DD
Operating Current (HIRC)
3V
f
SYS
=f
H
=8MHz
No load, all peripherals off
— 0.8 1.2 mA
5V — 1.6 2.4 mA
3V
f
SYS
=f
H
=12MHz
No load, all peripherals off
— 1.2 1.8 mA
5V — 2.4 3.6 mA
5V
f
SYS
=f
H
=16MHz, no load, all
peripherals off
— 3.2 4.8 mA
Operating Current (LXT)
3V
f
SYS
=f
SUB
=f
LXT
=32.768kHz
No load, all peripherals off
— 10 20 μA
5V — 30 50 μA
Operating Current (LIRC)
3V
f
SYS
=f
SUB
=f
LIRC
=32kHz
No load, all peripherals off
— 10 20 μA
5V — 30 50 μA
I
STB
Standby Current (IDLE0 Mode)
3V
f
SYS
off, f
SUB
on, No load,
all peripherals off, WDT enabled
— 1.3 3.0 μA
5V — 2.4 5.0 μA
Standby Current (IDLE1 Mode)
3V
f
SYS
=12MHz on, f
SUB
on, No load,
all peripherals off, WDT enabled
— 0.9 1.4 mA
5V — 1.4 2.1 mA
Standby Current (SLEEP Mode)
3V
f
SYS
off, f
SUB
off, No load,
all peripherals off, WDT enabled
— 1.2 1.8 μA
5V — 1.8 2.7 μA
V
IL
Input Low Voltage for I/O Ports or
Input Pins
5V — 0.0 — 1.5 V
— — 0.0 — 0.2V
DD
V
V
IH
Input High Voltage for I/O Ports or
Input Pins
5V — 3.5 — 5.0 V
— — 0.8V
DD
— V
DD
V
I
OL
Sink Current for I/O Pins
3V
V
OL
=0.1V
DD
17 34 — mA
5V 34 68 — mA
I
OH
Source Current for I/O Pins
3V
V
OH
=0.9V
DD
-5.5 -11.0 — mA
5V -11 -22 — mA
Programming Source Current for
I/O Pins *
3V
V
OH
=0.9V
DD
, PxPS[n+1:n]=00,
x=A, B, C, G or H, n=0 or 2
-1 -2 — mA
5V -2 -4 — mA
3V
V
OH
=0.9V
DD
, PxPS[n+1:n]=01,
x=A, B, C, G or H, n=0 or 2
-1.75 -3.50 — mA
5V -3.5 -7.0 — mA
3V
V
OH
=0.9V
DD
, PxPS[n+1:n]=10,
x=A, B, C, G or H, n=0 or 2
-2.5 -5.0 — mA
5V -5 -10 — mA
3V
V
OH
=0.9V
DD
, PxPS[n+1:n]=11,
x=A, B, C, G or H, n=0 or 2
-5.5 -11.0 — mA
5V -11 -22 — mA
R
PH
Pull-high Resistance for I/O Ports
3V — 20 60 100 kΩ
5V — 10 30 50 kΩ
*Note: 1. The I/O pins with programming source current are PA1, PA5~PA7, PB4~PB7, PC0~PC3 for BS66F340.
2. The I/O pins with programming source current are PA1, PA5~PA7, PB4~PB7, PC0~PC7 for BS66F350/
BS66F360/BS66F370, PG0~PG3, PH0~PH3 for BS66F370.
