BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Register
Name
Bit
7 6 5 4 3 2 1 0
PA PA7 PA6 PA5 PA4 PA3 PA2 PA1 PA0
PAC PAC7 PAC6 PAC5 PAC4 PAC3 PAC2 PAC1 PAC0
PAPU PAPU7 PAPU6 PAPU5 PAPU4 PAPU3 PAPU2 PAPU1 PAPU0
PAWU PAWU7 PAWU6 PAWU5 PAWU4 PAWU3 PAWU2 PAWU1 PAWU0
PB PB7 PB6 PB5 PB4 PB3 PB2 PB1 PB0
PBC PBC7 PBC6 PBC5 PBC4 PBC3 PBC2 PBC1 PBC0
PBPU PBPU7 PBPU6 PBPU5 PBPU4 PBPU3 PBPU2 PBPU1 PBPU0
PC PC7 PC6 PC5 PC4 PC3 PC2 PC1 PC0
PCC PCC7 PCC6 PCC5 PCC4 PCC3 PCC2 PCC1 PCC0
PCPU PCPU7 PCPU6 PCPU5 PCPU4 PCPU3 PCPU2 PCPU1 PCPU0
PD PD7 PD6 PD5 PD4 PD3 PD2 PD1 PD0
PDC PDC7 PDC6 PDC5 PDC4 PDC3 PDC2 PDC1 PDC0
PDPU PDPU7 PDPU6 PDPU5 PDPU4 PDPU3 PDPU2 PDPU1 PDPU0
PE PE7 PE6 PE5 PE4 PE3 PE2 PE1 PE0
PEC PEC7 PEC6 PEC5 PEC4 PEC3 PEC2 PEC1 PEC0
PEPU PEPU7 PEPU6 PEPU5 PEPU4 PEPU3 PEPU2 PEPU1 PEPU0
PF — — PF5 PF4 PF3 PF2 PF1 PF0
PFC — — PFC5 PFC4 PFC3 PFC2 PFC1 PFC0
PFPU — — PFPU5 PFPU4 PFPU3 PFPU2 PFPU1 PFPU0
I/O Registers List – BS66F360
Register
Name
Bit
7 6 5 4 3 2 1 0
PA PA7 PA6 PA5 PA4 PA3 PA2 PA1 PA0
PAC PAC7 PAC6 PAC5 PAC4 PAC3 PAC2 PAC1 PAC0
PAPU PAPU7 PAPU6 PAPU5 PAPU4 PAPU3 PAPU2 PAPU1 PAPU0
PAWU PAWU7 PAWU6 PAWU5 PAWU4 PAWU3 PAWU2 PAWU1 PAWU0
PB PB7 PB6 PB5 PB4 PB3 PB2 PB1 PB0
PBC PBC7 PBC6 PBC5 PBC4 PBC3 PBC2 PBC1 PBC0
PBPU PBPU7 PBPU6 PBPU5 PBPU4 PBPU3 PBPU2 PBPU1 PBPU0
PC PC7 PC6 PC5 PC4 PC3 PC2 PC1 PC0
PCC PCC7 PCC6 PCC5 PCC4 PCC3 PCC2 PCC1 PCC0
PCPU PCPU7 PCPU6 PCPU5 PCPU4 PCPU3 PCPU2 PCPU1 PCPU0
PD PD7 PD6 PD5 PD4 PD3 PD2 PD1 PD0
PDC PDC7 PDC6 PDC5 PDC4 PDC3 PDC2 PDC1 PDC0
PDPU PDPU7 PDPU6 PDPU5 PDPU4 PDPU3 PDPU2 PDPU1 PDPU0
PE PE7 PE6 PE5 PE4 PE3 PE2 PE1 PE0
PEC PEC7 PEC6 PEC5 PEC4 PEC3 PEC2 PEC1 PEC0
PEPU PEPU7 PEPU6 PEPU5 PEPU4 PEPU3 PEPU2 PEPU1 PEPU0
PF — — PF5 PF4 PF3 PF2 PF1 PF0
PFC — — PFC5 PFC4 PFC3 PFC2 PFC1 PFC0
PFPU — — PFPU5 PFPU4 PFPU3 PFPU2 PFPU1 PFPU0
PG PG7 PG6 PG5 PG4 PG3 PG2 PG1 PG0
PGC PGC7 PGC6 PGC5 PGC4 PGC3 PGC2 PGC1 PGC0
PGPU PGPU7 PGPU6 PGPU5 PGPU4 PGPU3 PGPU2 PGPU1 PGPU0
PH — — PH5 PH4 PH3 PH2 PH1 PH0
PHC — — PHC5 PHC4 PHC3 PHC2 PHC1 PHC0
PHPU — — PHPU5 PHPU4 PHPU3 PHPU2 PHPU1 PHPU0
I/O Registers List – BS66F370
