Honeywell CF3680 - Verifone Ruby Terminal Default Settings; Gilbarco Terminal Default Settings

N3680 Decoded Engine User Guide 9
ACK/NAK Mode
Verifone
®
Ruby Terminal Default Settings
Scan the following Plug and Play code to program the scan engine for a Verifone
Ruby terminal. This bar code sets the baud rate to 1200 bps and the data format to
8 data bits, no parity bit, 1 stop bit. It also adds a line feed (LF) suffix and programs
the following prefixes for each symbology:
Gilbarco
®
Terminal Default Settings
Scan the following Plug and Play code to program the scan engine for a Gilbarco
terminal. This bar code sets the baud rate to 2400 bps and the data format to 7
data bits, even parity, 2 stop bits. It also adds a carriage return (CR) suffix and pro-
grams the following prefixes for each symbology:
ACK/NAK Mode On
* ACK/NAK Mode Off
Symbology Prefix
UPC-A A
UPC-E A
EAN-8 FF
EAN-13 F
Verifone Ruby Settings
Symbology Prefix
UPC-A A
UPC-E E0
EAN-8 FF
EAN-13 F
Gilbarco Settings
