Honeywell DC1010 User Manual

Installation
8/05 DC1010/1020/1030/1040 Product Manual 5
INPUT ACTUATIONS
K
0.0~200.0, 400.0, 600, 800, 1000, 1200 °C
J
0.0~200.0, 400.0, 600, 800, 1000, 1200 °C
R
0.0~1600, 1769 °C
S
0.0~1600, 1769 °C
B
0.0~1820 °C
E
0.0~800, 1000 °C
N
0.0~1200,1300 °C
T
0.0~400.0, 200.0 °C, 0.0~350.0 °C
W
0.0~2000, 2320 °C
PL II
0.0~1300, 1390 °C
U
-199.9~600.0, 200.0 °C, 0.0~400.0 °C
TC
L
0.0~400.0, 800.0 °C
Pt100
-199.9~600.0, 400.0, 200.0 °C, 0.0~200.0, 400.0, 600.0 °C
JPt100
-199.9~600.0, 400.0, 200.0 °C, 0.0~200.0, 400.0, 600.0 °C
RTD
JPt50
-199.9~600.0, 400.0, 200.0 °C, 0.0~200.0, 400.0, 600.0 °C
Linear
AN4
AN5
0~50mV
10~50mV
0~20mA, 0~1V, 0~5V, 0~10V
4~20mA, 1~5V, 2~10V

Honeywell DC1010 Specifications

General

Control Type	On/Off, PID
Accuracy	±0.25% of span
Operating Temperature	0 to 50°C
Mounting	Panel Mount
Input Type	Thermocouple, RTD, mA, V
Output Type	Relay
Supply Voltage	100-240 VAC
Display	LED
Dimensions	48 x 48 mm
Number of Outputs	Up to 3
Enclosure Rating	IP66
Alarm	Up to 2 alarms
