Honeywell DC1010 User Manual

Configuration
8/05 DC1010/1020/1030/1040 Product Manual 39
Table 4-7 Linear Inputs
CODE SIGNAL INPUT TYPE RANGE
0 - 50mV
0-20mA, 0-1V, 0-5V, 0-
10V
-1999~9999
10 - 50mV
4-20mA, 1-5V, 2-10V
-1999~9999
*The default of Input Code is ‘AN5’ (4-20mA) for the model of linear input type.
(DC10X0X
L-XXX-XXX-X)
* DO NOT change the input type without technical assistance because it requires some
hardware changes on the input board in order to select a certain linear input type.

Honeywell DC1010 Specifications

General

Control Type	On/Off, PID
Accuracy	±0.25% of span
Operating Temperature	0 to 50°C
Mounting	Panel Mount
Input Type	Thermocouple, RTD, mA, V
Output Type	Relay
Supply Voltage	100-240 VAC
Display	LED
Dimensions	48 x 48 mm
Number of Outputs	Up to 3
Enclosure Rating	IP66
Alarm	Up to 2 alarms
