E-Mon® Series Global User Manual
Device configuration
Page | 60
54-000-01-ENG01-0121
5.1.2. Setup Sealing
Use the setup sealing button as mentioned in section Setup Sealing Button for locking in the
parameters which are used in during meter setup. Several the setup parameters are locked
with the help of the red setup sealing button.
The users are required to lock the sealing button post configuration to lock all the set
parameters for meter function. The list displays meter parameters on along with their access
rights when the sealing button is locked in. The list of parameters available in the meter are
enlisted in table below as per the status when the sealing switch is closed:
Read Only
Read / Write
• Meter connection diagram ID
• Nominal frequency
• Nominal voltage
• CS Ratio Primary
• CS Ratio Secondary
• Phase Direction System
• Clock
• Device ID
• Pulse ratio, Pulse Duration & React to
for Output 1 and 2.
• Display Backlight
• LED bar event color
• Threshold for missing voltage
• Display Language
• Display Labels
5.2. Configuration with Mobile Application
The E-mon® energy meter allows easy commissioning with mobile phone application. The
phone can be paired with meter using Bluetooth connectivity. Get the latest version of mobile
application before connecting with the meter. Use the E-Mon mobile App for meter
commissioning. Check the quick start guide for information on mobile pairing and
commissioning. Refer Table 1.
5.2.1. Mobile Phone to meter Pairing
1. Launch the E-Mon App on the mobile device.
2. Enable Bluetooth on your mobile phone.
3. Check for the meter is functioning and connected correctly.
4. Press the ‘Add’ (+) button on the App.
5. Enable Bluetooth connection for meter by using front panel.
6. Long press (3 Sec) the UP button for discovery mode.
