Pulse Meter Configuration
Page | 66
54-000-01-ENG01-0121
6.3. Pulse and Current Sensor (CS) Ratio Settings
The Pulse Ration requires to be in accordance with CS primary values. Check the CS rating
and the pulse ratio as mentioned in Section 4.4.3 (6) Setup Menu.
Here is a list of all the Pulse Ration settings with their respective CS Primary ratio:
CS Primary
Pulse Duration
Pulse Ratio
25 A
30
1000
50 A
30
1000
100 A
30
100
200 A
30
100
400 A
30
100
800 A
30
10
1600 A
30
10
2500 A
30
10
5000 A
30
10
The meter starts with a default Pulse Ratio value of 100 for a CS Primary range of 100 – 400
A. For CS with values other than the default range, the users are required to manually set the
Pulse Ratio as per the values mentioned in the table.
Once the Current sensors are installed with the energy meter, it is necessary to check the
Pulse ratio settings from the Setup menu. The Pulse Ratio must be set as per the values
provided in the table above.
