Programming Menu Quick Reference Programming Overview
Zone
Edit Zone Select Zone
Edit Zone Name Section 8.3.1
Zone Properties
Verification Type
*1-Count
2-Count
Alarm Ver.
PAS
SNGL ILOCK
DBL ILOCK
Heat Temp Set
135° to 150°F
135° to 190°F
Smoke Sensitivity Low
Medium
High
Zone Accessory
Opt
Single/Multi-station
Cadence
00-23
CO Single/Multi
station Cadence
00-23
Local Zone
Yes
No
View Zone Points Select Zone to View Section 8.3.2
Group
Edit Group Select Group
Group Name
Section 8.4.1
Group Properties
Template Override Y or N
Dynamic
Act/Template
Override Cadence
00-23
View Group Points Select Group
Edit Output Group
Templat e
Select Template Modify name and which Output Groups are in the template
Point
SK, IDP, or SD
Devices on Internal
SLC
Enter Pt Select Module
1,2
UNUSED
Section 8.5.1
SWITCH
1, 2, 3
MANUAL PULL
WATERFLOW
*LATCH
NON-LATCH
FIRE SUPERVSY
*LATCH
NON-LATCH
FIRE DRILL
SILENCE
RESET
P.A.S. ACK
ZONE AUX1
*LATCH
NON-LATCH
ZONE AUX2
LATCH
NON-LATCH
SYSTEM AUX1
LATCH
NON-LATCH
SYSTEM AUX2
LATCH
NON-LATCH
DETECTOR
FIRE TAMPER
LATCH
NON-LATCH
MANUAL RELEASE
INTERLOCK
Menu Options/Defaults Reference
Table 7.4 Programming Quick Reference List (Continued)
