Honeywell Impact Series User Manual

Impact / Impact Pro / Impact Pro IR Operating Instructions
44
User Menu
Flammable
Calibration
Operator
Instrument
Safelink
Language
u
Calibration
Span
Settings
Zero
u
Settings
Flm:
CO:
H2S:
50
100
40
%LEL
ppm
ppm
CH4
50
%LEL
Select the channel to change. The highlighted channel
settings can then be altered using the s (increase) and
t (decrease) buttons, holding the buttons down to
change the setting more rapidly. Press 3 to store the
new settings value.
Assuming catalytic flammable is chosen the instrument will request which calibration
gas is being used, irrespective of what the instrument is set to measure.
The calibration gas screen for IR sensors will not display a gas selection as the IR
sensors are limited in the selection of flammable gases - See Special Notes for
IR Sensors on page 65.
Select Gas
Propane
Butane
Methane
Pentane
Select Gas
-----
Catalytic Sensor IR Sensor
Honeywell Analytics recommends the following calibration gas concentrations:
Gas Type Concentration
Catalytic Flammable (%LEL): 50% LEL Methane
Flammable (%v/v): 2.5% v/v Methane
Carbon Monoxide: 100 ppm
Hydrogen Sulde: 40 ppm
Gas Type Concentration
Carbon Dioxide: 2% v/v
Methane (%LEL IR) 50% LEL Methane
Methane (%v/v IR) 50% v/v Methane
Carbon Dioxide (%v/v IR) 2% v/v
CAUTION
Performingamanualcalibrationusinggasesoutsidethesespeciedvalueswill
result in a calibration failure.
4�9�3 Flow Calibration – PC
In addition to the items required for flow adaptor calibration (Section 4.9.2), the user
will require the Impact Configuration Utility (ICU) PC software, serial cable, Base
Station and Power supply. These items can be purchased as part of the Datalogging
kit (available separately).
Place the Impact into the Base Station and ensure that the power supply and serial
cable are connected. Switch the Impact on, use Impact Configuration Utility (ICU)
software to perform calibration.
The instrument will display the readings while the calibration process is occurring
and the
symbol will be displayed in the center of the display.
Information, such as gas cylinder serial numbers, can also be entered for traceability.
Also, calibration reports can be printed.
