Impact / Impact Pro / Impact Pro IR Operating Instructions
17
2�2 Charge For First Use
Either a rechargeable battery pack or a dry-cell battery source can power the Impact.
For the rechargeable battery it must be charged before first use, to replace any
battery capacity used during transit and storage.
Ensure the Base Station is connected to a suitable power source.1.
Place the instrument in the Base Station.2.
The Base Station employs a locking mechanism to ensure that the Impact is
retained under most operating conditions. To ensure this operates correctly
the following procedure should be followed:
Ensure that the Impact is oriented such that the instrument lip will be a)
inserted under the locking lip.
Instrument Lip
Locking Lip
Front
Front
Insert the front of the Impact at an angle such that the instrument lip b)
slides under the locking lip.
Push down on the rear of the Impact such that the rear locking catch c)
engages.
To Next Page
