Honeywell Impact Series User Manual

Impact / Impact Pro / Impact Pro IR Operating Instructions
77
Appendix B
B�1 Warranty
Honeywell Analytics operates a standard warranty statement (See Page 3).
B�2 Certification Approvals
B�2�1 Impact/Impact Pro (non-IR) Approvals
Europe
CENELEC (ATEX) BAS 01 ATEX 1216
Ex 112G EEX ia d IIC T4 (-20°C to +55°C)
North America
UL Ex ia Class 1 Div 1 Group ABCD T4 T
amb
(-4°F to +131°F).
See Control Drawing for Safelink Connection
Australia
TestSafe AUS Ex 02.3809X
Ex ia s ZONE 0 I/IIB T4 (-20°C to +55°C)
EXAM
Performance
DMT 02 ATEX G 001
PFG Nr. 41300502
Canada
CSA Ex ia Class 1 Div 1 Group ABCD T4 T
amb
(-20°C to +55°C).
Brazil
Inmetro BR-Ex ia d IIC T4
T
amb
(-20°C to +55°C).
MDA (Australia)
AUS MDA GD 5053
The type-tested measuring ranges for
EXAM Performance approval
Measured Gas Range
Oxygen 0.0 to 25.0% v/v
Methane 0 to 100%LEL
Propane 0 to 100%LEL
Carbon Monoxide 3 to 500ppm
Hydrogen Sulde 0.4 to 50.0ppm
Carbon Dioxide 0.2 to 2.0% v/v
Zero Variation
(CO, H
2
S and CO
2
Channels)
Measured Gas Zero Variation
Carbon Monoxide 6ppm
Hydrogen Sulde 2ppm
Carbon Dioxide 0.25% v/v
Long Term Drift
(CO
2
channel after 1 month)
Measured Gas Zero Drift Span Drift
Carbon Dioxide 0.1% v/v 20% (relative)
Long Term Drift
(CO and H
2
S channels after 3 months)
Measured Gas Zero Drift Span Drift
Carbon Monoxide 1ppm 6% (relative)
Hydrogen Sulde 2ppm 2% (relative)
B�2�2 Impact Pro IR Approvals
Europe
CENELEC (ATEX) BAS 01 ATEX 1216
Ex 112G EEX ia d IIC T4 (-20°C to +55°C)
North America
UL Ex ia Class 1 Div 1 Group ABCD T4 T
amb
(-4°F to +131°F).
See Control Drawing for Safelink Connection
Canada
CSA Ex ia Class 1 Div 1 Group ABCD T4 T
amb
(-20°C to +55°C).
