Impact / Impact Pro / Impact Pro IR Operating Instructions
48
6�4 Offline Trickle Charger
(Part Number: 2302B141x)
Permits off-instrument charging of 2 or 4 instrument battery packs in
14 hours. It enables 24 hour availability of rechargeable instruments
with purchase of additional battery packs.
Battery packs must be charged in pairs. A power supply is included
in the trickle charger kit. Specify type when ordering:
UK EU US SAA
X = 4 X = 5 X = 6 X = 7
Example: Trickle Charger for US application = 2302B1416
The red LED indicates the batteries are receiving charge. Please note that the battery
packs must be charged in pairs, and may be left inserted indefinitely until required.
WARNING
The standard Power Supply unit must not be used when connecting multiple Base
Stations. Overheating of the Power Supply and ultimately failure will result.
6�5 Power Supply for Base Station and Trickle Charger
A range of suitable power adapters is available to power the base station or trickle
charger:
Power Supply Part Number
230VAC 50Hz Euro plug format 2302D0816
230VAC 50Hz UK plug format 2302D0818
120VAC 60Hz USA plug format 2302D0819
240VAC 50Hz Australian plug fmt 2302D0820
12V/24VDC vehicle charger lead 2302D0815
CAUTION
These individual Power Supplies will only supply power to one Base Station or
one Trickle Charger.
