Honeywell MC ToolKit User Manual

Generic HART Fields and Values
84 34-ST-25-20 MC Toolkit User Manual Release 3
9/06
Dialog Field Value
deka therm
foot pound force
Mjoule Mcalorie
Miscellaneous Hz
uMho
Percent,
pH
mSiemen/cm
uSiemen/cm
Newton
degBrix
% solids/wt
% solids/vol
degBalling
proof/vol
proof/mass
parts/million
degrees
radian
% consistency
volume %
ml/l
ul/l
% LEL
ppb
% SteamQual
ftin16
ft³/lb
pFarads
% plato
Generic Use Enumeration
Not Used
None
Unknown
Special
Transfer Function Linear
Square Root
Sq. Root 3rd Power
Sq. Root 5th Power
Special Curve
Square
Discrete(switch)
Sq. Rt+Spec. Curve
Sq. Rt 3rd+Spec.
Curve
Sq. Rt 5th+Spec.
Curve
Not Used
None
Unknown
PV Output Floating point
Alarm Direction High Low
NAMUR Not applicable for Generic HART transmitter
Poll Address 0 - 15
(Continued)
Req. Preambles Numerical
Primary Var. Code Numerical
Secondary Var. Code Numerical
Tertiary Var. Code Numerical
Dynamic
Variable Map
Quaternary Var. Code Numerical
Master Reset Performs a Master Reset of device
Device Status Displays the Device Status screen
Self Test Performs a Self Test of the device
Diagnostics/
Service
Monitor Displays the Monitor screen
Status Byte Status Byte 0 - Status Byte 15
Status Bit
Status Bit 0 - Status Bit 7
OK
Device Status
Non Critical Status (Field
Device Status)
Primary Variable
Out of Limits
Non Primary
Variable Out of
Limits
Loop Current
Saturated
Loop Current Fixed
More Status
Available
Cold Start
Configuration
Changed
Device
Malfunction
