Dialog Field Value
Monitor Output (mA) Floating point
Output (%) Floating point
PV Floating point
SV Floating point
TV Floating point
QV Floating point
Comm. Status String value
Device Status Displays the Device Status screen
Calibration Zero Trim Performs a Zero Trim
Apply Values Displays the Apply Values screen
Loop Test Displays the Loop Test screen
D/A Trim Displays the D/A Trim screen
Apply Values,
screen 1
Set the (output current to) 4 mA 20 mA
Apply Values,
screen 2
Current Applied Process
Value
Floating point
Set As New Value
Sets the LRV or URV equal to the value in the Current Applied
Process Value edit box.
Read New Value Updates the Current Applied Process Value edit box
Loop Test Mode Normal Output Mode
Choose Analog Output
Level
4 mA 20 mA Other
Other Floating point
Set Output Sets the device output
Clear Output Clears the Output Mode
D/A Trim
Field Device Will Be
Scaled From
Floating Point
Change Scale Activates the 2 edit boxes mentioned above.
Start D/A Trim Starts the D/A Trim process
Meter Value Floating point
Burst Mode Burst Mode Off
On
Not Used
None
Unknown
Special
Burst Options PV
% Range and
Current
All PVs and
Current
Specific
Monitor
Number of Device
Variables to Query
1 - 4
Dev. Var. 1 0 - 22
Dev. Var. 2 0 - 22
Dev. Var. 3 0 - 22
