Installing the MPA2 Panels
Installation
MPA2 Access Control Unit Installation Guide, Document 800-25395 - B 41
3.7 Communications
3.7.1 USB Communications
The MPA2 Controller Board provides a version 2.0 USB port that connects
to the web browser or to a MPC/WIN-PAK. The following figure identifies
the location of the port on the board.
Note: USB communication requires the USB A to MicroUSB B cable.
You will need to install a USB driver to support the connection. Follow these
steps:
Warning: Do NOT connect the USB cable to the panel until AFTER the
drivers are installed.
1. Insert the MPA2 Product CD into your Windows-based computer.
The MPA2 product menu opens in the web browser.
Note: If the product menu does not open automatically in your browser,
right click on the
Start button and select Explore. In the folder tree, find and
click the
CD drive that is reading the MPA2 Product CD.
