Installing the MPA2 Panels
Hardware Specifications
MPA2 Access Control Unit Installation Guide, Document 800-25395 - B 57
5.9 Panel label and Symbols
1. Panel label (Inside panel Door in metal housing MP2ENCM).
2. Symbols
Relay Outputs
Twisted Pair,
Shielded
CAT 6E/7 (S)/FTP
22-24 150 m (1000 Ft)
Table 10 Reader Wiring
Symbols Description
CE marking is a certification mark that indicates conformity with health, safety,
and environmental protection standards for products sold within the European
Economic Area (EEA). The CE marking is the manufacturer's declaration that the
product meets the requirements of the applicable EC directives
