Program Point Program
Soft Keys
CUSTOM ACTION MESSAGE: Enter the num
ber of the Custom Action Message to be displayed
during alarm conditions for this point (refer to Figure 3.28 on page 41 for an example).
VIEW: Press this
soft key to view the message associated with the number entered.
ACCEPT: Press to
save the entries made on this screen.
Sensitivity
Detector sensitivity levels for alarm and prealarm are s
et at this screen, which displays when the
SENSITIVITY soft key is pressed at the Detector Point Programming (2) screen.
Figure 3.36 Detector Sensitivity Screen
The control panel provides nine levels of Prealarm an
d Alarm i
n percent per foot obscuration, with
the following two exceptions:
• for heat detectors, the settings are in degrees Centigrade.
• for beam detectors, there are only
six levels of Alarm. There is no Prealarm for beam detectors
in CLIP mode.
• for Intelliquad FSC-851 detectors, there are only si
x levels of Alarm and Prealarm for
FlashScan mode, The sixth level is a fixed 135
o
F, and it is not available in CLIP mode.
Alarm sensitivity settings range from one to nine, with one representing the most sensitive alarm
level an
d nine the least sensitive.
Prealarm sensitivity settings range from
zero to nine. Zero indicates no prealarm. A value of one
can be a self-optimizing setting where the control panel selects a suitable prealarm level for the
detector. Values one or two through nine represent decreasing sensitivity, with nine being the least
sensitive.
Refer to the section “Detector Sensitivity Settings” in Appendix D, “Intelligent Sensing
Applications” for a full description and a table of the nine sensitivity levels by detector type.
Soft Keys
OCCUPIED SENSITIVITY ALARM:
OCCUPIED SENSITIVITY PREALARM:
UNOCCUPIED SENSITIVITY ALARM:
UNOCCUPIED SENSITIVITY PREALARM:
DETECTOR SENSITIVITY
L03D123
OCCUPIED UNOCCUPIED
SENSITIVITY SENSITIVITY
ALARM - 7 ALARM = 3
OCCUPIED UNOCCUPIED
SENSITIVITY SENSITIVITY
PREALARM - 5 PREALARM = 3
ALARM SENSITIVITY TABLE ACCEPT
1= 0.50% 4= 1.19% 7= 1.89%
2= 0.73% 5= 1.43% 8= 2.12%
3= 0.96% 6= 1.66% 9= 2.35% BACK
Press the soft key next to
these setting categories to
enter values as described
above.
To Next Page
