NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012 49
Point Program Program
ALARM SENSITIVITY TABLE: This table will toggle from ALARM to PREALARM based on
which sensitivity value is being entered. The table will display the values for this type of detector.
Detector Occupancy Schedule
Figure 3.37 Detector Occupancy Schedule Screen
Soft Keys
WEEKLY OCCUPANCY SCHEDULE: Press this
soft key to place the cursor at the underlined
field. There can be up to ten Weekly Occupancy Schedules. Enter a value of zero through ten. Zero
indicates no schedule is applied, and occupied detector sensitivity values are used.
ACCEPT: Press this
key to accept the change made and return to the previous screen.
Detector Point Programming (3)
Press the MORE soft key on the Detector Point Programming (2) screen to display this screen.
Figure 3.38 More Detector Point Programming (3) Screen
Soft Keys
LOW TEMP ENABLE: Press this
softkey to select YES or NO to enable the Low Temperature
Warning for the PHOTO/CO detector. This field is only available when programming a
PHOTO/CO smoke detector.
DETECTOR OCCUPANCY SCHEDULE
WEEKLY OCCUPANCY SCHEDULE: 10
SUNDAY - -
MONDAY 08:00-12:00, 13:00-18:00
TUESDAY 08:00-12:00, 13:00-18:00
WEDNESDAY 08:00-12:00, 13:00-18:00
THURSDAY 08:00-12:00, 13:00-18:00
FRIDAY 08:00-12:00, 13:00-18:00
SATURDAY 08:00-12:00, -
HOLIDAY UNOCCUPIED
ACCEPT
BACK
DETECTOR POINT PROGRAMMING
L03D123
LOW TEMP ENABLE: YES
PREALARM:ALERT
CO PRE-ALARM: YES
SILENCEABLE:NO
INTELLIGENT SOUNDER:YES ACCEPT
SOUNDER BASE SETUP BACK
