54 NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012
Program Point Program
Pressing the THRESHOLD SETUP soft key at the Module Point Programming screen will display
this screen.
Figure 3.43 FMM-4-20 Threshold Setup Screen
Soft Keys
THRESHOLD NUMBER: Enter the threshold number (1 - 5) that will be described in this screen.
THRESHOLD VALUE: Enter the value for this threshold. (Threshold value is represented in the unit
type specified on the FMM-4-20 Device Setup Screen)
EVENT: Select the event type that will generate when this threshold is reached. Selections are NO
EVENT,TROUBLE, FIRE, SUPERVISORY, SECURITY, NONFIRE, CRITICAL PROCESS.
TROUBLE TYPE: Select a trouble type for this threshold: TROUBLE 1, TROUBLE 2 or DEVICE
INHIBIT. Device Inhibit will generate a trouble when the FMM-4-20 is in a self-calibration state.
EVENT TRIGGER: Select LOWER LEVEL (values are falling), UPPER LEVEL (levels are rising), or
SAME LEVEL.
TRACKING/LATCHING: Select TRACKING or LATCHING for the threshold trouble. If more than
one threshold has been programmed as latching, the first threshold reached will be the one that is latched.
ACCEPT: Press to save screen entries.
MODULE POINT PROGRAMMING
L03M150
THRESHOLD NUMBER 1
THRESHOLD VALUE: 500.25
PPM
EVENT TROUBLE LATCHING
TROUBLE TYPE: TROUBLE1 ACCEPT
EVENT TRIGGER: LOWER LEVEL BACK
To Next Page
