NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012 53
Point Program Program
LOCAL MODE: Press to toggle between Local Mode (ON) or no Local Mode (OFF). When there is
a communication loss between the panel and its LCM/LEMs, SLC devices that have been selected
for Local Mode participation (ON) will continue to function across all the panel’s SLCs in a limited
manner as follows: input points will activate output points of the same Type Code point type
designations. For example, SLC inputs with “fire” point types will activate SLC outputs with “fire”
point types. Refer to Appendix G.3, “Type Codes for Input Devices”, on page 138 for Type Code
point types. This setting is fixed at OFF fo
r the FMM-4-20
module. Default: OFF
4-20 DEVICE SETUP: Press to go
to FMM-4-20 programming. (Refer to “FMM-4-20 Monitor
Module Programming” on page 53“FMM-4-20 Monitor Module Programming” on page 53) This
field appears only when FMM-420
appears as the module’s Type Code label.
MORE: Press to access
the third Module Point Programming Screen.
ACCEPT: Press to
save entries made on this screen and to return to the previous screen.
FMM-4-20 Monitor Module Programming
Pressing the 4-20
DEVICE SETUP soft key at the Module Point Programming screen will display
this screen.
Figure 3.42 FMM-4-20 Device Setup Screen
Soft Keys
4MA SCALE VALUE: Enter the 4 mA value.
20MA SCALE VALUE: Enter the 20 mA value.
UNITS: Type in the kind of units. (5 spaces.)
HYSTERESIS: Enter the hysteresis value in decimals as a percentage of the overall 4 to 20 mA range.
Default: 0
THRESHOLD SETUP: Press to continue to the THRESHOLD SETUP screen. (Refer to Figure 3.43
on page 54)
ACCEPT: Press to save entries made on this screen.
NOTE: The panel setting LCM LOCAL MODE must be set to YES for local mode to work at the
device level.
MODULE POINT PROGRAMMING
L03M150
4MA SCALE VALUE: 0.00
20MA SCALE VALUE: 2000.00
UNITS: PPM
HYSTERESIS: 02.0% ACCEPT
THRESHOLD SETUP BACK
