NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012 55
Point Program Program
Pressing the MORE soft key on this Module Point Programming screen will display this screen:
Figure 3.44 Module Point Programming Screen 3 (Monitor)
WATERFLOW DELAY: When the WATERFLOW DELAY option is set to 0 , waterflow events are
immediately reported to the panel upon activation. If a non-zero value is entered in the WATERFLOW
DELAY, activation of a waterflow event is delayed for the duration of that time. The waterflow event will
have to remain active for the duration of the delay. If the waterflow event does not remain active for the entire
delay duration, the waterflow event will not be reported to the panel.
Default:
0
Range: 0-60 seconds
ACCEPT: Press to save screen entries.
Module Point Programming (Control Module)
Pressing the MORE soft key at the Module Point Programming screen will display this screen if the
module type was control.
Figure 3.45 Module Point Programming Screen 2 (Control)
MODULE POINT PROGRAMMING
L03M150
WATERFLOW DELAY:30
ACCEPT
BACK
MODULE POINT PROGRAMMING
L03M150
LOCAL MODE:ON
ZONE MAP:
Z000 , Z104 , Z105 , Z106 , Z107
Z110 , Z114 , Z115 , Z116 , Z117
WALK TEST: OFF
SWITCH INHIBIT: YES ACCEPT
SILENCEABLE:NO BACK
Zone Map Position 1 - Use for group zone
disable participation.
To Next Page
