Honeywell TC300

26 Home screen: Temperature reading and adjustment
2 - OVERVIEW
Home screen: Temperature reading and adjustment
Table 13: Home screen (main screen) Overview
Item Description
1 Time
2 Alarm status
3 Adjust temperature: Touch the up arrow to increase the desired temperature.
4 Desired temperature: Displays the desired temperature.
5 Adjust temperature: Touch the down arrow to decrease the desired temperature.
6 Fan Speed: Indicates current Fan speed for Fan Coil unit. Tap to change the fan speed.
7 Home screen indicator: Use finger to swipe to left or right to display more options.
8 System Mode Display: Orange flame for heat mode, blue snowflake for cool mode.
9 Indoor Temperature: Displays the current indoor temperature.
10 Current Schedule: Indicates the current Occupant status (Occupied, Unoccupied, Standby,
Temporary)
10
9
8
1
3
4
5
7
6
2
