64 Managing System switch
4 - CONFIGURATION
To configure Control sensors
The thermostat groups the control sensors into three types. There are Local sensor,
Remote sensor, and Multi sensor.
Local Sensor: Internal TC300 temperature sensor. Installer can configure offsets to
on-board temperature and humidity sensors, if desired.
Remote Sensor: Space temperature sensor connected to UI/UIO terminal, or TR40
sensor configured at address 2.
Multi Sensor: Local Sensor and Sylk sensors at address 2, 3, 4, 5 used together to
calculate space temperature.
1. Swipe left from the Home screen.
2. On the Quick access screen, tap > Equipment > Sensor Settings > Control Sensors.
The Control sensors screen appears. By default, it shows Local Sensors. If Remote
Sensors are also configured then Multi-Sensors and Remote Sensors also appear.
Figure 43 Control sensors
Note: If the relevant sensors not available then it will be grayed out.
Managing System switch
To configure system switch
1. Swipe left from the Home screen.
2. On the Quick access screen, tap > Equipment > System Switch.
The System switch screen appears.
