Managing Setpoints 93
MANAGING SETPOINTS
Figure 84 System status
Managing Setpoints
To configure setpoint settings
1. Swipe left from the Home screen.
Table 28: System status
Operating status Equipment type, Current operating mode, Heat status, Cool status, Aux heat,
Fan status, Indoor temperature, Indoor setpoint, Indoor humidity, Indoor
CO2, Discharge air temperature, Discharge air control setpoint, Pipe
temperature, Recovery status, Override remaining, Run time, Restart reason,
Terminal load, UTC offset
Schedule Current schedule time, Current occupancy state, Current schedule state,
Next schedule state, Time to next schedule state,
Configurable I/O All terminals ON/OFF status.
Device Model name, Boot loader version, Firmware version, Application version,
UUID, Serial No.
Network status For BACnet MS/TP: Device ID, MAC address, Baud rate. For Modbus:
Address, Baud rate, Parity, Stopbits
Service Service personnel name and phone number.
