Honeywell TC300 User Manual

Managing Pipe sensor thresholds 75
MANAGING PIPE SENSOR THRESHOLDS
Managing Pipe sensor thresholds
This feature is suitable for heating when pipe temperature is above threshold, and
suitable for Cooling when pipe temperature is below threshold.
To configure Pipe sensor thresholds
1. Swipe left from the Home screen.
2. On the Quick access screen, tap > Advanced > Pipe Sensor Thresholds.
The Pipe Sensor Thresholds screen appears.
Figure 54 Pipe Sensor Thresholds
Fan Delay Fan On Delay
Time
0 to 30 Sec
Default 30
Fan on delay time after heating outputs are turned
on. May be used to run fan after heating outputs
have turned on for some times so that heating coil
can warm up.
Fan Off Delay
Time
0 to 180 Sec
Default 120
Sec
Fan run on time after all heating outputs are turned
off. May be used to run fan after all heating outputs
have turned off so that the heat coil can cool down
before the fan turns off.
Table 25: Heating options (Continued)
Heating
type
Configuration
Type
Range Description
Table 26: Pipe sensor threshold
Operation Configuration
Type
Range Description
Heat/Cool
Thresholds
(Standard)
Pipe Sensor
Threshold for
Heating
70 to 90°F (Default
80°F)
When the pipe temperature is above the
threshold, it is suitable for heating.
Pipe Sensor
Threshold for
Cooling
45 to 65°F (Default
60°F)
When the pipe temperature is below the
threshold, it is suitable for cooling.
