14 Thor VM1A Vehicle-Mounted Computer
Power Cable Cautions
• Route power cable away from the outside of the fork truck.
• Choose a mounting location so that the power cable does not extend outside the
vehicle and that provides sufficient clearance so that the power cable (especially
the dock connector end) is not pressed against part of the vehicle.
• Use the proper
Strain Relief Cable Clamps to secure cable.
• The power cable is less flexible in low temperature environments. Avoid sharp
bends.
Power Cable Routing
Caution: When routing the power cable:
Caution: Regularly inspect power cable for damage, especially in low
temperature environments. Contact
Technical Assistance for
replacement cable options.
Power cable with right-angle connector
Avoid sharp bends in this
area of the power cable
Power cable with straight connector
To Next Page
