Thor VM1A Vehicle-Mounted Computer 73
Enhanced Dock with Thor VX8/VX9 Screen Blanking
This dock is designed for use when the Thor VM1A is replacing a Thor VX8 or Thor
VX9. This dock utilizes the existing vehicle wiring from the earlier computer and
supports screen blanking through that wiring.
Note: For the VMX Enhanced Dock: COM1 is used for screen blanking (via the power cable
connector) and is unavailable when the screen blanking box is attached. When a
screen blanking box is attached, any external serial device, such as a scanner, must
be connected to the COM2 port on the dock. If a screen blanking box is not connected
via the power cable, the COM1 port on the dock is available for a serial device.
VMXD Enhanced Dock for Off-Vehicle Use
SKUs VMX004VMCRADLE
Power Connection Direct or DC/DC power supply
Serial Ports COM1 and COM2 by means of DB9 male connectors (See note below)
USB Ports USB1 port provides host connection via an adapter cable
USB2 port provides two USB host ports via an adapter cable
Direct USB host type A connection
Ethernet RJ-45 Ethernet connection on top of dock
Audio Headset connection via an adapter cable
Screen Blanking Supported via COM1 and COM2 connectors
Ignition Control Not supported
Caution: This dock is designed for AC power (non vehicle-mounted)
applications only.
SKUs VMX005VMCRADLE
Power Connection AC/DC adapter
Serial Ports COM1 and COM2 by means of DB9 male connectors
USB Ports USB1 port provides host connection via an adapter cable
USB2 port provides two USB host ports via an adapter cable
Direct USB host type A connection
Ethernet RJ-45 Ethernet connection on top of dock
Audio Headset connection via an adapter cable
Screen Blanking Not supported
Ignition Control Not supported
