Honeywell Thor VM3 Manual

1 - 2
Le présent appareil est conforme aux CNR d'Industrie Canada applicables auxappareils radio exempts de licence.L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage adioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Conformité des appareils de radiocommunication aux limites d'exposition humaine aux radiofréquences (CNR-102)
L'ordinateur utilise des antennes intégrales à faible gain qui n'émettent pas un champ électromagnétique supérieur aux normes
imposées par Santé Canada pour la population. Consultez le Code de sécurité 6 sur le site Internet de Santé Canada à
l'adresse suivante : http://www.hc-sc.gc.ca/
L'énergie émise par les antennes reliées aux cartes sans fil respecte la limite d'exposition aux radiofréquences telle que définie
par Industrie Canada dans ldu document CNR-102, version 5.
This radio transmitter has been approved by Industry Canada to operate with the antenna types listed below with the maximum
permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for
that type, are strictly prohibited for use with this device.
Immediately following the above notice, the manufacturer shall provide a list of all antenna types approved for use with the trans-
mitter, indicating the maximum permissible antenna gain (in dBi).
5GHz Statement
UNII-1 Band (5150-5250 MHz) is in passive/listen mode only and will not actively initiate communication.
ANATEL (Brazil)
Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de
estações do mesmo tipo, e não causar interferência a sistema operando em caráter primário.
警告
此为 A 级产品，在生活环境中，该产品可能会造成无线电干扰，在这种情况下，可能需要用户对干扰采取切实可行的措施。
Vehicle Power Supply Connection Safety Statement
Note: For North America, a UL Listed fuse is to be used
For proper and safe installation, the input power cable must be connected to a fused circuit on the vehicle. If the supply connec-
tion is made directly to the battery, the fuse should be installed in the positive lead within 5 inches (12.7 cm) of the battery’s pos-
itive (+) terminal. Use VM3055FUSEKIT (or equivalent) to install the fuse as shown below:
•For 12VDC input, use the 10A in VM3055FUSEKIT or a slow blow fuse that has a DC voltage rating greater than 12VDC.
•For 24VDC input, use the 6A in VM3055FUSEKIT or a slow blow fuse that has a DC voltage rating greater than 24VDC.
•For 36VDC input, use the 4A in VM3055FUSEKIT or a slow blow fuse that has a DC voltage rating greater than 36VDC.
•For 48VDC input, use the 3A in VM3055FUSEKIT or a slow blow fuse that has a DC voltage rating greater than 48VDC.
Li-Ion Battery
When disposing of the Thor VM3 UPS battery, the following precautions should be observed: The battery should be disposed of
properly. The battery should not be disassembled or crushed. The battery should not be heated above 212°F (100°C) or inciner-
ated.
Description Type Gain Manufacturer
External wifi antenna, dual band 2.40-
2.50G/4.90-5.90G. Dual Band Swivel
Mount. Dipole RP-TNC Blade
R380500314
2.4 ~ 2.5Ghz: 1.6dBi
4.9 ~ 5.9Ghz: 5dBi
LARSEN
External Two-Way Radio Antenna WTS 2450
2.4 to 2.485Ghz: 2.1dBi
4.9 to 5.9Ghz: 2.6dBi
LAIRD Technologies
Internal PIFA antenna
FIT-VM3-ANT-21Y 2.4GHz: 4.25dBi
Venture GES Singapore Pte Ltd
(Designed by:
Frontier Integrated Technology)
FIT-VM3-ANT-028 5.0GHz: 5.5dBi

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
