Honeywell Thor VM3 Manual

6 - 1
6
Wireless Network Connections
Managing Wireless Connections
The Thor VM3 has an 802.11 a/b/g/n WLAN radio and an optional WWAN radio.
• The WLAN radio is configured using the WLAN Wireless Configuration Utility (WCU) (page 6-1).
• The WWAN radio is configured using the VM3 WWAN Connection Manager (page 6-36).
• The VM3 Connection Manager also provides configuration options for roaming between WLAN and WWAN connections.
WLAN Wireless Configuration Utility (WCU)
The 802.11 wireless client device is a Qualcomm Atheros AR950 802.11 a/b/g/n WLAN adapter. This wireless radio is config-
ured by the Wireless Configuration Utility (WCU).
Dynamic vs. Fixed IP Address
When changing between dynamic and fixed IP address (Select (Start) > All Apps > Windows System > Control Panel
> Network and Sharing Center > Change Adapter Settings, right-click on desired adapter and select Properties > Inter-
net Protocol Version 4 (TCP/IPv4) > Properties) be sure to reboot the Thor VM3 after changing the IP address type.
Important Notes
Using the Wireless Configuration Utility
Note: When finished making changes the device should be restarted afterwards.
(Start) > All Apps > Honeywell > Honeywell (version ID) > WCU or
WCU Icon on Desktop
It is important that all dates are correct on the Thor VM3 and host computers when using any type of certificate. Cer-
tificates are date sensitive and if the date is not correct authentication will fail.
When using the 802.11 radio, the U-NII 1 band is the preferred band for indoor operation. For regulatory domains in
which the U-NII 3 band is allowed, the following channels are supported: 149, 153, 157 and 161. The AP must be
configured accordingly.
When using any profile that requires the user to enter credentials (user name, password), the user should enter those
credentials when the window pops up. If the credentials are not entered then, the credentials window may be hidden
by other windows.
!
Status
Profile List
Tasks
!

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
