5 - 47
Launching Configuration Cloning Utility GUI
1. Locate the CCU icon either on the desktop or by selecting (Start) > All Apps > > Honeywell >Configuration Clon-
ing.
2. Right-click on the icon.
3. Select Run as administrator to launch the CCU.
If a User Account Control message is displayed, you must allow the CCU to make changes to the computer.
Using Configuration Cloning Utility GUI
Menu Options
File
The File menu contains information for working with the configuration files.
About
Displays version and copyright information for the Configuration Cloning Utility.
Open
Opens a configuration file. The CCU looks for configuration files in the C:\Windows\DDF folder. CCU can
open the following files types:
ddf files - These files contain the factory default values for the software. These files are placed on the Thor
VM3 when the applicable software was installed or upgraded. Use this option if you wish to start a
configuration settings file based on the factory defaults.
ccf files - These files contain the modified values for the software settings. These files are created with the
CCU . ccf files are encrypted for security. Once a ccf file is created on one Thor VM3 it can be copied to
other Thor VM3s to duplicate the configuration. An existing ccf file can be opened, modified, applied to the
Thor VM3, saved, saved with a different name, etc.
Close
Closes the open data file.
It is necessary to run the CCU as an administrator because the CCU must be able to access and make changes to
the Windows registry.
Rather than selecting to run as administrator each time, right-click on the CCU icon and select Properties. Tap the
Compatibility tab and check Run this program as an administrator. This modification affects the current user only
unless Change settings for all users is tapped before changing the privilege level.
!
