Page #146 background imageLoading...
Page #146 background image
5 - 48
Save
Saves the open data file as a ccf file.
If a ccf file was opened, it is saved with the same name and in the same location.
If a ddf file was opened, a prompt is displayed for the name to assign to the new ccf file. By default a new
file is saved at C:\Windows\DDF though a different location can be specified.
Save As
Saves the open data file as a ccf. If a ccf file was opened, this option allows a new name or location for the
data file to be specified during the save process.
Exit
Exits the CCU. A prompt may be displayed if there are unsaved ccf changes.
Edit
Provides access to the standard Windows Cut, Copy and Paste functions. These functions can be used to manip-
ulate the settings within the configuration file.
Registry
Reads values from and writes values to the system registry.
Import Settings
Imports the current settings from the Windows registry for the selected application(s). When selected, the
available programs from which settings can be read are displayed in a tree format.
Apply Settings
Applies the current settings to the Windows registry for the selected applications. During the process, a
Default all Non-Configured Parameters prompt is displayed:
Tap Yes to set all parameters not configured in the ccf file to defaults on the destination device.
Tap No to apply the values from the ccf file and leave all other parameters as-is on the destination device.
Tap Cancel to exit with no changes to the destination device.
Upon completion, exit the CCU and reboot the Thor VM3 so changes can take effect.
User
Selects the desired user access level:
Basic - Basic users can open files and import setting from the system registry. Basic users cannot modify
settings from an opened file or setting imported from the registry. Basic users can apply setting to the system
registry.
Advanced - Advanced users can open files and import settings registry. Advanced users can modify the values
from either an opened file or imported from the system registry. Advanced users can apply settings to the
system registry.
Shortcuts
The table below lists the valid shortcut key combinations within the CCU.
Shortcut key Action
CTRL + A Opens About screen
CTRL + O Opens folder with CCF files (C:\Windows\DDF)
CTRL + C Closes the open file (only valid when a ccf or ddf file
CTRL + S Application is saved
CTRL + E Application is closed
CTRL + X Cuts the data
CTRL + C Copies the selected data to the clipboard
CTRL + V Pastes the data from the clipboard at the current location
CTRL + I Displays import setting list
