Honeywell Thor VM3 Manual

5 - 37
Screen Control
(Start) > All Apps > Windows System > Control Panel > Screen (Large or Small Icon View)
Set screen properties for the Thor VM3.
Factory Default Settings
Note: If automatic brightness control is enabled for an outdoor display, the value for LCD brightness depends on the
Ambient Light %.
Note: There is no default value for Ambient Light % as it varies depending on the level of light where the Thor VM3 is
located.
Automatic Brightness Control
When the Thor VM3 is equipped with an outdoor display, automatic brightness control can be enabled. When
enabled, display brightness is based on ambient light detected by the ambient light sensor, located near the top right of
the display. The default is disabled. To enable, check the Enable automatic brightness control checkbox and spec-
ify the thresholds for display backlight transition.
When enabled, the thresholds can be entered for display brightness transitions.
• When a low level of ambient light is detected, the display backlight is set to low level.
• When the ambient light exceeds the threshold specified in Low to medium light level (%), the display backlight is
automatically increased to a medium level.
• When the ambient light exceeds the threshold specified in Medium to high light level (%), the display backlight is
automatically increased to a high level.
• Likewise if the Thor VM3 is returned to a lower ambient light area, the display backlight automatically transitions to
the appropriate lower display backlight level.
Automatic Brightness Control
(for outdoor display only)
Enable automatic brightness control Disabled
Low to medium light level (%) 25
Medium to high light level (%) 75
Current Level
LCD Brightness (%) 100 (see note)
Defroster Control
Enable defroster Enabled
Trip point (ºC) 40ºC

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
