Honeywell Thor VM3 Manual

9 - 2
VM3D Enhanced Dock
VM3D Enhanced Dock
Power Connector 6-pin connector:
Direct10-60V DC input power
Optional external converters for AC (90-240 VAC) and extended range DC (60-150
VDC)
COM1Connector 9-pin male, RS-232 serial port, COM1 with switchable power on pin 9
COM2 Connector 9-pin male, RS-232 serial port, COM2 with switchable power on pin 9
CANBUS/AUDIO Connector 15-pin male, CANbus/Audio connector supports either audio/microphone via adapter
cable or J1939 Female and J1939 Male connectors via CANbus cable
USB1 Connector 9-pin female, USB connector supports USB host port via adapter cable
USB 2 Connector 15-pin female, USB connector supports 2 USB host ports via adapter cable
USB Host Connector One USB Host connector behind waterproof cap
Ethernet Connector One RJ45 Ethernet connector behind waterproof cap
Power Switch Sealed power switch
External Power Supply AC Adapter, 120-240VAC to 12VDC
Input Power DC Input Voltage: 10- 60 VDC,
Input Current: 4.6 Amps (typical),
Input Fuse: 8A Time Delay. Replace with same size, rating and type of fuse:
• Littelfuse 0215008.MXP
• Cooper Bussmann BK1/S506-8-R
• Bel Fuse 5HT 8-R
or equivalent.
Power Connector 6-pin connector:
13.2VDC input power
Connector is also used for screen blanking via COM1 CTS and RTS signals
COM1Connector 9-pin male, RS-232 serial port, COM1 with switchable power on pin 9
Do not use COM1 when screen blanking box is attached to avoid port conflicts.
COM2 Connector 9-pin male, RS-232 serial port, COM2 with switchable power on pin 9
CANBUS/AUDIO Connector 15-pin male, CANbus/Audio connector supports either audio/microphone via adapter
cable or J1939 Female and J1939 Male connectors via CANbus cable
USB1 Connector 9-pin female, USB connector supports USB host port via adapter cable
USB 2 Connector 15-pin female, USB connector supports 2 USB host ports via adapter cable
USB Host Connector One USB Host connector behind waterproof cap
Ethernet Connector One RJ45 Ethernet connector behind waterproof cap
Power Switch Sealed power switch
External Power Supply AC Adapter, 120-240VAC to 12VDC
Input Power DC Input Voltage: 13.2VDC,
Input Current: 4.6 Amps (typical),
Input Fuse: 8A Time Delay. Replace with same size, rating and type of fuse:
• Littelfuse 0215008.MXP
• Cooper Bussmann BK1/S506-8-R
• Bel Fuse 5HT 8-R
or equivalent.

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
