Honeywell Thor VM3 Manual

2 - 4
There are three type of docks available for the Thor VM3. Features of the docks are described below:
Note: For the VX4D Enhanced DOCK: COM1 is used for screen blanking (via the power cable connector) and is unavailable
when the screen blanking box is attached. When a screen blanking box is attached, any external serial device such as a
scanner, must be connected to the COM2 port on the connection.dock. If a screen blanking box is not connected via the
power cable, the COM1 port on the dock is available for a serial device.
VM1D Standard Dock VM3D Enhanced Dock
VMXD Enhanced Dock
(for Thor VM3 replacing Thor
VX8 and Thor VX9
SKUs VM1001VMCRADLE (with RAM
ball)
VM1002VMCRADLE
VM1003VMCRADLE
VM3001VMCRADLE VMX004VMCRADLE
Power
Connection
Direct, DC/DC Adapter, AC/DC
Adapter
Direct, DC/DC Adapter, AC/DC
Adapter
Designed to connect to existing Thor
VX8 or Thor VX9 power cable only
Serial
Ports
COM1 and COM2 COM1 and COM2 COM1 and COM2
(see note below)
USB Ports USB port provides host connec-
tion via an adapter cable. This
port also supports Honeywell
external keyboards.
USB1 port provides host connec-
tion via an adapter cable. This
port also supports Honeywell
external keyboards.
USB2 port provides two USB host
ports via an adapter cable.
Direct USB host connection on top
of dock.
USB1 port provides host connec-
tion via an adapter cable. This
port also supports Honeywell
external keyboards.
USB2 port provides two USB host
ports via an adapter cable.
Direct USB host connection on top
of dock.
Ethernet N/A RJ-45 Ethernet connection on top of
dock.
RJ-45 Ethernet connection on top of
dock.
CANbus CANbus connection via an adapter
cable
CANbus connection via an adapter
cable
CANbus connection via an adapter
cable
Audio Headset connection via an adapter
cable
Headset connection via an adapter
cable
Headset connection via an adapter
cable
Screen
Blanking
Supported via COM1 and COM2
connectors.
Supported via COM1 and COM2
connectors.
Supported via power cable connec-
tor. (see note below)
Ignition
Control
Supported Supported Not supported

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
