Honeywell Thor VM3 Manual

6 - 26
To save changes, tap Apply the button. Confirmation dialogs may be displayed.
To exit without saving changes, tap the X in the upper right of the window.
Tap restore default values, tap the Restore Default Values then tap Apply.
Radio
Logging Enable When checked, logging is enabled. Logging can be set to Critical (fewer messages)
or All (more messages). Logging is disabled by default.
Note: Logging is set to disabled after any reboot to prevent log files for taking up
disk space when not needed.
Minimum Connection Time
(sec)
The minimum connection time the radio stays connected to the current access point
before roaming begins. Default 10 seconds, range is 5 to 25.
Roam RISSI Difference (dBm) The minimum signal strength difference between APs before the radio roams. De-
fault 5 dBm, range is 5 to 25.
Background Scan
Signal Level (dBm) The minimum signal strength an access point signal must have to be considered for
roaming. Default -65 dBm, range is -80 to -55.
Probe Request Interval (sec) The interval between roam probes. Default 5 seconds, range is 5 to 60.
CCX Control
Note: For CCX to be enabled, two settings must be enabled:
• CCX must be enabled (checked) on this screen.
• Enable Atheros Connection Settings must be enabled (checked) on the Connection (page 6-5) tab.
If both settings are not enabled, the WLAN radio does not identify itself as CCX V4 compatible when associating to
an access point.
CCX Use CCX (Cisco Client Extensions) for faster roaming. Default is enabled.
CCKM Use CCKM (Cisco Centralized Key Management) for faster roaming. Default is en-
abled.
Power Save Set the power save level. Options are Off (default) and Auto-PSM.
Band Selection Select the bands to use. Options are: A, BG, G, ABG (default).
DatRate Selection To limit data rates, check the Limit DataRate checkbox. If checked, select the desired rate (MCS0
to MCS15). MCS0 (Modulation and Coding Scheme) 0 is slowest, MCS15 is fastest but subject
to more errors. Default is disabled.

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
