SYS (System Status) LED
UPS Status LED
The color of the UPS LED identifies the charge level, while the behavior of the LED identifies the charging state.
Charge Level
Charging State
UPS Unavailable
SSD (Solid State Drive) LED
LED Behavior System State
Solid Green • On
• On but Backlight Off
• On but Display Off
Off
External power present
• Off
Off
External power not present
• Suspend
• Hibernate
• Standby/Sleep
• Off
LED Color Status
Green Fully charged (>90%)
Amber Less than fully charged, but more than 2 minutes runtime remaining
Red Low battery, less than 2 minutes runtime until shutdown
LED Behavior Status
Slow Blink
(1 sec. on, 3 sec. off)
Charging
Fast Blink
(1/2 sec. on, 1/2 sec. off)
UPS supplying power and discharging
On Neither charging or discharging
Off Unit is off or is in SuspendHibernate
LED Behavior Status
Super Fast Blink
(1/8 sec. on, 1/8 sec. off)
• Out of charging temperature range
• Charge timeout
• UPS is not installed
LED Behavior Status
Flashing Green SSD read or write activity
Off No SSD read or write activity

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
