CHAPTER 13: ETHERENET COMMUNICATION
13.1 Ethernet Module Protocols and Features
The following table describes the Ethernet Module Protocols and features supported by the
Ethernet port on the EXL6.
Table 13.1 – Ethernet Module Protocols & Features
Protocol / Feature
Protocol / Feature Description
ICMP (Ping)
Internet Control Message Protocol
EGD (Ethernet Global
Data)
Ethernet Global Data
SRTP Slave (90-30
Service Request)
Service Request Transfer Protocol
CsCAN TCP Server
Horner APG CsCAN over Ethernet (for Cscape to OCS programming)
Modbus Slave
Modbus over Ethernet
Ethernet / IP
ODVA CIP over Ethernet
FTP (File Server)
File Transfer Protocol
ASCII over TCP/IP
ASCII Data over Ethernet
NTP Protocol
Network Time Protocol (Obtain clock from web-based server)
HTTP ( Web Server)
Hypertext Transfer Protocol (Web Server)
13.2 Ethernet System Requirements
Full Ethernet functionality requires:
- PC running Cscape Programming Software Version 9.3 SP6 or later (for configuration).
- EXL6 controller with onboard Ethernet port.
13.3 Ethernet Module Specifications
Table 13.2 – Ethernet Module Specifications
Speeds
10 BaseT Ethernet (10Mbps)
100 BaseTx Fast Ethernet (100Mbps)
Modes
Half or Full Duplex
Auto-Negotiation
Both 10/100Mbps and Half/Full Duplex
Connector Type
Shielded RJ-45
Cable Type
(Recommended)
CAT5 (or better) UTP
Port
Auto MDI/MDI-X (Auto Crossover)
