CHAPTER 3: MECHANICAL INSTALLATION
NOTE: The datasheet is the first document to refer to for model-specific information related to
EXL6 OCS models such as pin-outs, jumper settings, and other key installation information. Visit
the Horner websites to obtain datasheets, user documentation, and updates.
North America https://hornerautomation.com
Europe http://www.hornerautomation.eu
3.1 Overview
The mechanical installation greatly affects the operation, safety and appearance of the system.
Information is provided to mechanically install the unit such as cut-out sizes, mounting
procedures and other recommendations for the proper mechanical installation of the unit.
3.2 Mounting Requirements
3.2.1 Mounting Procedures (Installed in a Panel Door)
Figure 3.1 – Panel Mounting of an EXL6 Series OCS
