4.3 How to Test for Good Ground
In order to test ground resistance, a Ground Resistance Tester must be used. A typical Ground
Resistance Meter Kit contains a meter, two or three wire leads, and two ground rods. Instructions
are supplied for either a two-point or three-point ground test.
Figure 4.1 – Two-Point Ground Connection Test
